CT10

The Compacttilt CT10 is a hydraulic tilt for excavators in the 6 to 10 tonne class. Using the patented cylinder-free motor technology, the CT10 tilts the attachment 2×50 degrees — 100 degrees in total — exceeding the industry standard of 90 degrees. This enables precise levelling and digging in positions and angles a standard tilt cannot reach.

• Cylinder-free design – no hydraulic cylinders on the sides of the excavator arm. The CT10 stays no wider than the arm itself, giving free passage in narrow trenches, alongside cables and pipes, and close to foundations where space is tight.
• Narrow profile (288 mm) – the CT10 is no wider than the excavator arm. This makes it possible to dig foundation trenches to a line and work in tight slots that a wider tilt simply cannot access.
• Low weight – at 82 kg the CT10 is light for its class, preserving as much of the machine’s lifting capacity as possible.
• Installation height from 250 mm, preserving the machine's breakout forces and the ability to dig a sharp edge close to the machine.
• S45, Hydrema and CW10 quick couplers – the CT10 is supplied in the configuration that suits your machine.

The CT10 is the first choice when large excavators need to carry out precise work: trench digging, foundation trenches, levelling, digging alongside pipes and cables — and any job that demands an attachment that fits where there is no space to spare.

Need rotation as well?

If you also need continuous rotation alongside tilting, CTR10 is the solution for the same machine class. The CTR10 uses the same cylinder-free motor technology and is equally suited to the 6–10 tonne segment.
